This is the Ruger P-Series Blocker Lever, factory part number KV02112, for the DA/SA and decocker P-Series pistols from the P89 through the P95.
One part number covers the entire safety/decocker line across three calibers and roughly two decades of production — the frames, slides and barrels changed model to model, the blocker lever did not. The double-action-only guns are the exception: Ruger’s factory parts list for the P89DAO through P944DAO calls out a different blocker lever, KV02113. Every P-Series pistol uses an automatic firing pin safety that keeps the firing pin blocked until the trigger is pulled fully to the rear, and this lever is part of that system.
Condition: Used, pulled from service, all three serviceable. Photographed from both sides. All three retain their original matte finish over the investment-cast surface, with color running from light gray to charcoal — normal variation between production runs, not damage. No rust or pitting. Light handling marks and some dulling on the flats. The pivot hole through the raised boss is open and reads round on all three, with no cracking or distortion around it. The stepped upper edge and the notch are crisp, the lower leg is whole, and all three read straight and true.
Included: One of the blocker levers pictured. Sold individually.
Fits:
- P95, P95PR, P95DPR
- P89, P89DC
- P94, P94DC
- P90, P90DC
- P944, P944DC
- P93DC
- P91DC
Does not fit:
- Any DAO model — P89DAO, P91DAO, P93DAO, P94DAO, P944DAO, P95DAO. Those take KV02113.
- P85. The P85 uses a different sear and blocker arrangement.
- P97, P97DC, P97DAO and P345.
Fitting: This is a fire control part in the automatic firing pin safety, and it should be installed by a gunsmith. After assembly and before loading, function check the pistol thoroughly: verify the firing pin block returns to the blocking position when the trigger is released, verify the pistol will not fire without a full trigger pull, and on decocker and safety models verify the decocker drops the hammer without discharging and that the safety holds. Do not put the pistol into service until it passes.
Please note: Buyer is responsible for verifying correct fit for their specific firearm. Installation should be performed by a qualified gunsmith. Please review all photos, as they are part of the description and show the actual item you will receive.
Condition: Original matte finish over the cast surface, color varying from light gray to charcoal between pieces. No rust or pitting. Pivot holes open and round, edges crisp, all are straight and true.
Additional information
| Weight | 0.2 lbs |
|---|---|
| Dimensions | 7 × 5 × 0.5 in |
| Part |
Blocker Lever |
| Brand |
Ruger |
| For Gun Make |
Ruger |
| Model |
Ruger P89 P90 P91 P93 P94 P944 P95 (Not DAO) |
| Gauge/Caliber |
All Calibers |
| For Gun Type |
Handgun|Auto Pistol |
| Country of Origin |
United States |
| Color |
See Photos |
| Material |
Steel |
| MPN |
KV02112 Blocker Lever |
